9 kW
A+

Zefiro 9

9 kW
A+
Pellet inserts – Pellet Air

The pellet insert that adapts to your needs and that integrates perfectly with open fireplaces. The pellet loading system is customizable with two extraction options, hatch or drawer. With an optional kit, you can direct the air to warm other rooms in the building. Large glass window, so the fire can be admired.


Heatable volume min/max
98/252 m3

Hopper capacity
15 kg

Cast iron inner with 2nd combustion air

Ducting kit (optional)

Comfort mode

Integrated Wi-Fi

Integrated Bluetooth

Connection to the external thermostat

Upper exhaust


Available finishes

Stove packing:
L 80 cm H 72 cm P 71 cm

Stove packing:
L 80 cm
H 72 cm
P 71 cm

Available finishes

Select the finish to view

Glass
Black

Technical data

Nominal power
9 kW

Heating input
9,9 kW

Heatable volume min/max
98/252 m3

Heatable surface min/max
36/93 m2

Hopper capacity
15 kg

Range min/max
8/19 h

Hourly consumption min/max
0,8/2 kg/h

Nominal performance
90%

Reduced performance
91%

Reduced power
3,5 kW

Net weight
94 kg

Pellet fuel
Ø 6 mm

Exhaust fumes
Ø 80 mm

Hole combustion air inlet
Ø 60 mm

Ducting outlet
Ø 80 mm


Features

Sealed chamber

Cast iron burning pot

Cast iron inner with 2nd combustion air

Ducting kit (optional)

Comfort mode

Integrated Wi-Fi

Integrated Bluetooth

Remote control (optional)

Connection to the external thermostat

Daily weekly programming

Upper exhaust


Certifications

Certificate model name: ZEFIRO 9 T2


7018023
