18 kW
A++

Saturno 16

18 kW
A+
Pellet inserts – Pellet Hydro
Saturno is a hydro insert featuring a minimalist design, supplied with hydraulic kit, front ventilation and adjustable pellet loading. Available in 16 kW and 24 kW versions.

Heatable volume min/max
165/513 m3

Hopper capacity
40 kg

Integrated Bluetooth

Connection to the external thermostat

Air temperature sensor

Scarico fumi superiore

Available finishes

Stove packing:
L 95 cm H 124,5 cm P 75 cm

Stove packing:
L 95 cm
H 124,5 cm
P 75 cm

Available finishes

Select the finish to view

Steel
Black

Technical data

Nominal power
18 kW

Heating input
19,1 kW

Heatable volume min/max
165/513 m3

Heatable surface min/max
61/190 m2

Hopper capacity
40 kg

Range min/max
10,3/33,3 h

Nominal useful water power
13 kW

Reduced useful water power
3,8 kW

Hourly consumption min/max
1,2/3,9 kg/h

Reduced power
5,8 kW

Nominal performance
94,2%

Reduced performance
95,9%

Net weight
230 kg

Pellet fuel
Ø 6 mm

Exhaust fumes
Ø 100 mm

Hole combustion air inlet
Ø 50 mm

Features

Cast iron burning pot

Integrated Wi-Fi

Integrated Bluetooth

Connection to the external thermostat

Water temperature sensor

Air temperature sensor

Daily weekly programming

Connection to the heating system

Hydraulic kit included

Upper exhaust

Scarico fumi superiore

Certifications

Show more

Certificate model name: SATURNO 16

7020016
